Product Description
Product Description
4-Pin Turn Brake Lamp & Inner Tail Light for Tesla Model 3 & Model Y
Restore damaged or failed rear lighting with vehicle-specific 4-pin replacement lamp assemblies designed for the original Tesla mounting positions. Choose the outer turn/brake lamp, trunk-mounted inner tail lamp, or a combined set in left, right or paired configurations.
4-PIN required · OE-number verification · Left / Right / Pair
🔌
4-Pin Direct Replacement
Built for compatible Tesla rear-light systems using the 4-pin electrical connector. The connector must be verified before ordering.
💡
LED Rear Lighting
Integrated LED illumination restores the corresponding rear lighting function while maintaining an OEM-style lens shape and appearance.
🧩
Left, Right or Pair
Replace only the failed side or order a matching pair, with separate configurations for outer turn/brake lamps and trunk-mounted inner tail lamps.
Match the Exact Lamp Instead of Replacing the Entire Rear Set
🚘
Outer turn & brake lamp
The body-mounted outer lamp assembly is available separately when only the primary turn/brake light housing needs replacement.
📦
Inner tail lamp
The inner lamp mounts on the trunk / liftgate side of the rear lighting system and can be replaced independently from the outer lamp.
🔢
OE-number matching
Current 4-pin versions use different OE references for left/right and outer/inner lamps, helping prevent ordering the wrong electrical or physical configuration.
🏭
Plant-specific selection
The current manufacturer selector distinguishes Fremont/Texas and Shanghai/Berlin production groups. Do not rely on model year alone.
🛠️
Factory-location installation
The assemblies are designed around the original Tesla mounting locations and connector system rather than requiring a universal aftermarket bracket.
4-PIN Verification Is Mandatory
Remove or inspect the existing lamp connector and confirm that it has 4 pins before ordering.
Vehicles using a 3-pin connector require the separate 3-pin product version.
Confirm the OE Number Before Ordering
Turn Brake Lamp — Left
OE Reference:
1502086-00-D / 1502086
Turn Brake Lamp — Right
OE Reference:
1502087-00-D / 1502087
Inner Tail Light — Left
OE Reference:
1502088-00-B / 1502088
Inner Tail Light — Right
OE Reference:
1502089-00-B / 1502089
Do Not Order by Model Year Alone
Tesla rear-light configurations can vary by production plant, market and connector generation. Verify the existing OE label and 4-pin connector before selecting the replacement.
Vehicle-Specific Replacement Installation
Current TESKAY Model 3
2021–2023.10
Current TESKAY Model Y
2020–2025.3
Connector
4-PIN Only
1. Check the OE Label
Confirm the current lamp's part number and whether you need the outer Turn Brake Lamp or trunk-mounted Inner Tail Light.
2. Confirm the 4-Pin Connector
Inspect the electrical plug and verify that the vehicle uses the four-pin version before removing the old lamp.
3. Access the Lamp Mounting Area
Remove the necessary trunk, liftgate or rear interior trim to access the original lamp connector and mounting hardware.
4. Remove the Original Lamp
Disconnect the factory plug and release the original lamp from its mounting points without pulling on the vehicle wiring.
5. Install the Replacement
Position the replacement assembly in the factory location, secure it using the corresponding mounting points and connect the matching 4-pin harness.
6. Test Before Reassembly
Verify all functions provided by the selected lamp and vehicle configuration before reinstalling interior trim.
Plug-and-Play Electrical Connection
Current manufacturer information describes the replacement as using the original vehicle connector without cutting or splicing the factory wiring.
Inner-Lamp Functions Can Vary by Market
Tesla rear-light functions can differ by market and production configuration, including reverse/fog-light behavior. Match the connector and OE number rather than assuming every inner lamp performs exactly the same function.
Specifications
| Attribute | Details |
|---|---|
| Product | 4-Pin Turn Brake Lamp & Inner Tail Light Replacement |
| TESKAY Model 3 Selection | 2021–2023.10 |
| TESKAY Model Y Selection | 2020–2025.3 |
| Connector | 4-PIN Required |
| 3-PIN Vehicles | Require Separate 3-PIN Product Version |
| Plant Options on Current Source | Fremont/Texas Giga / Shanghai/Berlin Giga |
| Available Types | Turn Brake Lamp / Inner Tail Light / Both |
| Position Options | Left / Right / Pair |
| Turn Brake Lamp — Left OE | 1502086-00-D / 1502086 |
| Turn Brake Lamp — Right OE | 1502087-00-D / 1502087 |
| Inner Tail Light — Left OE | 1502088-00-B / 1502088 |
| Inner Tail Light — Right OE | 1502089-00-B / 1502089 |
| Light Source | LED |
| Housing | Manufacturer-Listed Weather-Resistant ABS Shell |
| Installation | Factory-Location Direct Replacement |
| Wire Cutting / Splicing | Not Required on Matching Configuration |
| Vehicle Coding | Not Specified as Required |
| Published IP Rating | Not Published |
| Published Wattage | Not Published |
| Package | Selected Lamp Type and Quantity Based on Model / Plant / Position Selection |
Quick Answers
Is this the 4-pin or 3-pin tail light? +
This product is specifically the 4-pin version. Confirm the existing vehicle connector has four pins before ordering.
Can I use this if my Tesla has a 3-pin connector? +
No. A vehicle with a 3-pin connector requires the dedicated 3-pin replacement version.
Does it fit Model 3? +
Current TESKAY selection lists Model 3 2021–2023.10. Confirm the 4-pin connector and OE number before purchase.
Does it fit Model Y? +
Current TESKAY selection lists Model Y 2020–2025.3. Connector and OE-number verification are still required.
What is the difference between Turn Brake Lamp and Inner Tail Light? +
The Turn Brake Lamp is the outer body-mounted rear lamp. The Inner Tail Light is the smaller rear lamp mounted on the trunk or liftgate side.
Can I buy only one side? +
Yes. Current options include Left, Right and Pair.
Can I buy both the outer and inner lamps together? +
Yes. Select the Inner Tail Light & Turn Brake Lamp configuration and then choose Left, Right or Pair.
Why do I need to check the manufacturing plant? +
Tesla lighting hardware can vary by production plant and market. The current source distinguishes Fremont/Texas from Shanghai/Berlin configurations.
What OE number should I look for? +
Current 4-pin references are 1502086-00-D left outer, 1502087-00-D right outer, 1502088-00-B left inner and 1502089-00-B right inner.
Is 1077402-00-B the only correct OE number? +
No. Some older product text still references 1077402-00-B, but the current 4-pin product selector publishes separate OE references for left/right outer and inner lamp assemblies. Match the label on your existing lamp.
Is installation plug-and-play? +
The electrical connection is designed to plug into the matching factory connector, but physical trim and lamp removal are still required.
Do I need to cut factory wiring? +
No wire cutting or splicing is specified when the correct 4-pin lamp configuration is selected.
Does it require Tesla software coding? +
Current manufacturer installation information does not list software coding as a required step for a matching replacement.
Is this a styling upgrade or a replacement lamp? +
It is primarily an OEM-style replacement solution for a damaged or failed compatible lamp assembly rather than a completely redesigned aftermarket taillight set.
Is an IP waterproof rating published? +
The manufacturer describes the housing as weather resistant, but no verified IP65 or IP67 rating is published on the current 4-pin page.
